zPULSE 2.0
Ultra-wide, compact 4D Imaging Radar for Infrastructure and Autonomous Systems
zPULSE 2.0
Compact, Ultra-Wide 4D Software-Defined Imaging Radar
zPULSE 2.0 is our compact, ultra-wide imaging radar platform for infrastructure, stationary sensing, and autonomous systems that need broad coverage from a small sensor. Available in both 60GHz and 77GHz configurations, zPULSE gives customers the flexibility to deploy high-performance radar perception across a wide range of markets and regulatory environments.
Its ultra-wide field of view and industry-leading angular resolution makes zPULSE well suited for traffic monitoring, smart infrastructure, industrial automation, security, and mobile robotics deployments.
zPULSE is more than a high-performance radar. Build on our third-generation digital beamforming architecture and SDIR platform, zPULSE gives developers control and unlocks flexibility of the radar configuration. Output behavior can be adapted to the application on a case-by-case basis.
One platform. Three layers of software.
zPULSE 2.0 is part of the broader Zadar sensing and perception platform. RSP Core provides flexible operating modes and industry-leading point cloud output. RDP Developer provides data-processing toolboxes to process for you to build custom perception solutions using radar. RSP Studio gives advanced teams the ultimate control over RF parameters and signal processing performance.
Built for Global Infrastructure Deployment
The 60GHz version of zPULSE enabled radar deployment in applications and regions where 77GHz operation is restricted or unavailable, while the 77GHz version supports markets where automotive-band radar is preferred.
How much you build is your call.
Customers can deploy zPULSE as a standalone radar sensor, develop their own perception stack with RDP Developer, or use a complete Zadar solution, all while retaining the same underlying sensor platform.
| zPULSE Specifications 120° × 90° · IP68 | |
|---|---|
| Radar performance | |
| Field of View | 120° × 90° |
| Static Angular Resolution | 1.5° |
| Angular Accuracy | ±0.25° |
| Truck Detection | > 400 m |
| Car Detection | > 400 m |
| Human Detection | > 200 m |
| Hardware | |
| Hardware Dimensions | 80 × 70 × 40 mm |
| Weight | 200 g |
| Weather Proofing | IP68 (2-meter) |
Tell us what you need to see.
Send us the scene, the mounting height, the coverage, the weather, the thing that has to be detected before it matters. We'll tell you which configuration fits, and whether radar is the right answer at all.
